Dynamode KVM-8701 Ficha Técnica descarregar pdf

KVM-8701

8 Port Automatic KVM Switch, with Daisy chain OSD, black

INTRODUCTION

APPLICATION

Think about the following: you have 2, 3, 4, or more computers or servers in the same room or

location, all with their own monitor, keyboard and mouse. If you only needed to use 1 monitor, 1

keyboard, and 1 mouse to control them all, think about how much space and money you could save!

Plus, you'll never need to move around the room to use the computers or servers again; all you'll need

is the Dynamode PC or Server KVM with On Screen Display and daisy chain capabilities for ease of

use.

High quality multimedia, Presentation, Video Conference.

Public broadcasting system, Education, Training.

Demo, Stock market, Bank, Security.

Dynamode

SPECIFICATION

Description

8 PCs to 1 user

PC side

HD-15M x 8

Console side

HD-15F x 1, MD-6F x 2

Max. Resolution

1920 x 1440

Video bandwidth

250MHz

Horizontal Frequency

30-180KHz

Vertical Frequency

43-250Hz

Transmission distance

- Computer to KVM-8701: 10 meters

- Console to KVM-8701: 5 meters

Case Design

19" Rack-mounted

Dimension

436.5mm x 190mm x 43mm

Daisy Chain

Yes

Power

DC 12V

Dynamode 1
